Price: $1,570-2,770
Capacity: 80-1500m³/h
Belt width: 500-1400mm
Application areas: Sand Screening,Coal,Gravel,Aggregates,Recycling,Demolition,Construction Waste,Heavy Overburden,Iron Ore,Topsoil,Rock
The Handling Materials and Applicaiton of Belt Conveyor
Our belt conveyors feature large capacity, simple structure, easy maintenance, and standardized parts. Widely used in mining, metallurgy, coal, and similar industries, they transport bulk materials or finished goods. Configure single or multiple units into horizontal/inclined systems to suit various layouts. Operating range: -20°C to +40°C; material temperature: ≤50°C.
| Technical data | ||||||
| Model | Belt width (mm) | Maximum material force (mm) | Capacity Q (t/h) | Conveying length L(m) | Power (kw) | Conveying speed (m/s) |
| B500 | 500 | 0~100 | 80-100 | L≤10 | 4 | 0.8-1.6 |
| 10＜L≤22 | 5.5 | |||||
| 22＜L≤46 | 7.5 | |||||
| B650 | 650 | 0~130 | 150-200 | 6＜L≤19 | 7.5 | 0.8-1.6 |
| 19＜L≤44 | 11 | |||||
| 44＜L≤50 | 15 | |||||
| B800 | 800 | 0~180 | 250-300 | 8＜L≤23 | 11 | 0.8-1.6 |
| 23＜L≤38 | 15 | |||||
| 38＜L≤50 | 18.5 | |||||
| B1000 | 1000 | 0~250 | 400-500 | L≤11 | 11 | 1.25-1.6 |
| 11＜L≤20 | 15 | |||||
| 20＜L≤28 | 18.5 | |||||
| 28＜L≤36 | 22 | |||||
| 36＜L≤50 | 30 | |||||
| B1200 | 1200 | 0~300 | 600-700 | L≤10 | 15 | 1.25-1.6 |
| 10＜L≤16 | 18.5 | |||||
| 16＜L≤22 | 22 | |||||
| 22＜L≤35 | 30 | |||||
| 35＜L≤45 | 37 | |||||
| 45＜L≤50 | 45 | |||||
| B1400 | 1400 | 0~350 | 1000-1500 | L≤9 | 22 | 1.6-2 |
| 9＜L≤16 | 30 | |||||
| 16＜L≤20 | 37 | |||||
| 20＜L≤28 | 45 | |||||
| 28＜L≤36 | 55 | |||||
| 36＜L≤50 | 75 | |||||
Optimized Hopper Design: Specifically engineered hopper prevents material bridging and ensures continuous flow onto the conveyor belt.
Cost-Effective Installation: Permanently installed structure eliminates transport reassembly costs, providing global economic efficiency.
Hybrid Power Integration: Onboard electric motor enables flexible operation via external power sources or integrated diesel engine.
Stationary Stability: Fixed foundation design delivers unparalleled operational stability for heavy-duty material handling.
Configurable Specifications: Customizable lengths, belt widths, and hopper capacities to match feeding systems and production requirements.
Precision Feed Control: Variable-speed belt feeder regulates material flow from hopper to discharge point with millimeter accuracy.
